SVEN Power Smart 2000

Catalog Electrical Equipment Uninterruptible Power Supplies SVEN Power Smart 2000

SVEN Power Smart 2000

Short product description:

Digital microprocessor control
High efficiency
Wide range of auto voltage regulation (АVR)
Sinusoidal output voltage both in on-line and off-line mode ...

All features

Similar products

SVEN KB-G9700

SVEN KB-G9600

SVEN KB-G9500

SVEN KB-G9450

SVEN KB-G9400

SVEN KB-G9300

SVEN KB-G9200

SVEN KB-G9150

SVEN KB-G8900

SVEN KB-G8800

SVEN KB-G8600

SVEN KB-G8500

SVEN KB-G8400

SVEN KB-G8300

SVEN KB-G8200

SVEN KB-G8000

SVEN KB-G7400

SVEN GS-9200

SVEN GS-9100

SVEN GS-9000

SVEN GS-4300

SVEN KB-E5900W

SVEN KB-E5800W

SVEN KB-E5800

SVEN KB-E5700H

SVEN KB-E5500

SVEN KB-E5500W

SVEN KB-E5300W

SVEN KB-E5000

SVEN KB-C7500EL

SVEN KB-C7150EL

SVEN KB-C3800W

SVEN KB-C3600W

SVEN KB-C3500W

SVEN KB-C3400W

SVEN KB-C3200W

SVEN KB-C3060

SVEN KB-C3010

SVEN KB-C3000W

SVEN KB-C2550W

SVEN KB-C2300W

SVEN KB-C2100W

SVEN KB-S330C

SVEN KB-S320C

SVEN KB-S307M

SVEN KB-S305

SVEN KB-S302

SVEN KB-S300

SVEN KB-S230

SVEN Standard 304 USB+HUB

SVEN Standard 303 Power USB+PS/2

SVEN Standard 303

SVEN Standard 301

SVEN Comfort 3300 Wireless

FEATURES
SPECIFICATIONS
DESCRIPTION
UNBOXING VIDEO
SUPPORT

Digital microprocessor control
High efficiency
Wide range of auto voltage regulation (АVR)
Sinusoidal output voltage both in on-line and off-line mode
Built-in surge protector
Highly informative vdisplay indicating variables and basic operation modes
Option of off-line operation mode sound signal switch-off by pressing a button on the front panel
Sound alarm at critical discharge level of storage batteries (without switch-off option)
USB and RS-232 communication port
Nominal output voltage set by the user
Impulse suppression connector for network equipment (modem, fax) protection
Cold Start function at DC power supply
Battery charge level indication in on-line and off-line mode
Automatic recharge and deep battery discharge prevention system (ABM system)
Automatic electricity delivery mode at power supply renewal
Passive ventilation allows noiseless operation
Short-circuit and overload protection
Convenient and simple battery replacement

Maximum load, VA/W	2000/1200
Input voltage level, V	220/230/240 ± 25 % (determined by the user )
Output voltage level, V	220/230/240 +12 % … -14 % (on-line), 220/230/240 +3 % … -10 % (off-line)
Output voltage waveform	sine wave (on-line), sine wave (off-line)
Frequency, Hz	50/60 (determined by the user )
Communication port	USB, RS-232
Input terminals	IEC 320 (plug)
Output sockets	IEC 320 from the inverter (6 pieces)
Protection	from high input current, short circuit, overload, lightning stroke, voltage surges, falls, brownouts, blackouts. Modem / telephone circuit protection
Alarm signals	30 dB beeps at a distance of 1 meter
Accumulator type	maintenance-free sealed lead-acid batteries (consumables)
Accumulators capacity	12 V × 7 А h (4 pieces)
Typical switching time, ms	4
Batteries operation time, min	4.3/11.7 (full load/half load)
Indicators	of operating modes, level of battery load and charge, AVR operating modes, correct networking and grounding
Processor	on basis of RISC-microprocessor
Controlled variable	current input and output voltage, frequency, output power, battery condition and charge level, temperature inside the case
Environment operation conditions	<5000 m above sea level, 0-50 °C, moisture 0 - 90% without condensation
Supported interfaces	intelligent software support of Win Mе/NT/2000/XP/Vista
Certificates	UL. cUL, FCC, [CE,TUV] РосТест
Floating time	4 hours (up to >85 %), 10 hours max (up to >90 %)
Dimensions (W × H × D), mm	173 x 472 x 247
Weight, kg	23
Life time	5 years
